FG/FP70x70-2500-R7016

Aluminum fence post 70x70 mm-2.5 m, Anthracite RAL 7016, for 40 mm wide infills and angled mounting of louver infills

Name: Aluminum fence post 70x70 mm-2.5 m, Anthracite RAL 7016, for 40 mm wide infills and angled mounting of louver infills
Brand: umakovshop-com
SKU: FG/FP70x70-2500-R7016
Price: 52.66 EUR
Availability: InStock

Material: Aluminium, Surface finish: Textured powder coating, Effect: Antracit RAL7016

€52,66

without VAT

€64,77

with VAT

Stock availability

SK Krompachy > 25

SK Banská Bystrica 0

SK Bratislava R1 0

SK Senec 0

Contact

For more information, please contact our sales:

lubomir.petruska@umakov.sk

+421915093533 +393483490444

Description

Aluminum fence post 70 × 70 mm – 2.5 m – Anthracite RAL 7016 – for 40 mm wide lamella and angled mounted louver infills

Product code: FG/FP70x70-2500-R7016

Material
Extruded aluminum EN AW-6063-T6.
High resistance to corrosion and weathering.

Surface finish
Powder coating with a fine texture, Anthracite RAL 7016 shade.
Trendy matte look and long-term color stability.

Dimensions
Cross-section: 70 × 70 mm.
Length: 2500 mm (2.5 m).
Designed for mounting 40 mm wide lamellas, well 40 mm wide other infills, and angled mounting of louver infills.
Possibility of shortening or ordering other length variants.

Assembly and compatibility
Screwed mounting system allows quick installation without welding.
Easy disassembly and replacement of individual parts.
Compatible with lamellas and system profiles with a thickness of 40 mm.
Designed for anchoring 40 mm wide lamellas (product code FG/S40x...) using self-drilling screws (product code A-DIN 7504K-A2 4.2x13).
Designed for anchoring 20 mm wide lamellas using an aluminum fence reduction (product code FG/RDC40...) with self-drilling screws (product code A-DIN 7504K-A2 4.2x13).
Designed for angled anchoring of louver infills (product code FG/L1S20x105...), (product code FG/L1S40x99...), (product code FG/O20x100...) using self-drilling screws (product code A-DIN 7504K-A2 4.2x13).
Compatible with caps (product code FG/CP70x70-R7016), (product code YDG06AL01-70x70/7016-G), (product code E2/282-70x70).
Compatible with aluminum anchoring plate (product code FG/BP120x120x10-R7016).
Compatible with Click lock cover strip (product code FG/AF49x17...).
Compatible with Click-lock cover strip (product code FG/AF41x9...) and Click-lock spacer cover strip (product code FG/AF41x9-NOL-05-SET) and (product code FG/AF41x9-OL-05-SET).
Possibility of shortening or ordering other length variants.
Available accessories: anchoring plates, cover strips, end elements and A2 stainless steel fasteners.

Advantages
Larger cross-section for higher strength and structural stability.
Optimized for 40 mm wide lamella and other infills, well angled anchoring of louver infills, with or without gaps.
Infills can be combined to achieve a modern and elegant look that suits various fencing styles and architecture.
The system allows mounting for straight lamellas, angled louver infills, decorative panels, photovoltaic panels, LED lighting, etc., in combination with all types of gates and wickets.
Color and decor: wide range of RAL shades and surface textures.
Replacement of damaged parts: easy disassembly and reassembly without special tools.
Final surface treatment: no need for further coatings.
No cracks from expansion: powder coating does not crack even with temperature changes.
Quick assembly: screwed system saves time and costs.
Minimal maintenance: regular cleaning is sufficient.
