Narrow cover strip for post profiles and for U-adapter of fence system, 20 x 08 – 6.0 m – Anthracite RAL 7016
Contact
Contact
For more information, please contact our sales:
Narrow cover strip for post profiles and for U-adapter of fence sys...
Description
Narrow cover strip for post profiles and U-adapter of fence system 20 × 8 mm – 6.0 m – Anthracite RAL 7016
Product code: FG/PC20x8-6000-R7016
Material
• Extruded aluminium EN AW-6063-T6.
• High resistance to corrosion, moisture and weather conditions.
Surface finish
• Powder coating with fine texture, shade Anthracite RAL 7016.
• Modern matte appearance, long-term color stability and UV resistance.
Dimensions
• Functional cross-section of the cover strip: 20 × 8 mm.
• Profile length: 6000 mm (6.0 m).
• Possibility of shortening required or delivery in other length variants.
Assembly and compatibility
• Screwed fence and facade mounting system – quick installation without welding.
• Easy disassembly and replacement of individual parts during modifications or damage.
• Use a cover strip for profiles 50×60 (product code FG/P50x60...), 70×70 PRO (product code FG/PRO70x70...), 80×80 (product code FG/P80x80...).
• Use a cover strip for U-adapters MODEL 20PRO (product code FG/A20...) and MODEL 20PV (product code FG/AT16...) of the fence system.
• After shortening, it can also be used a spacer cover strip.
• Compatible with Umakov profiles and accessories.
• Accessories: stainless steel fasteners A2.
Advantages
• Easy replacement or disassembly of individual parts during maintenance or damage.
• No need for further surface treatment – durable powder coating.
• Quick assembly with a screwed system – saving time and costs.
• Minimal maintenance – regular cleaning is sufficient.
Parameters
